| Place of Origin: | Jiangyin, China |
| Brand Name: | Ecohydraulic |
| Model Number: | SRM600 |
| Certification: | ISO, CE |
| Minimum Order Quantity: | 1 set |
| Price: | FOB Shanghai, USD10000~USD15000 |
| Packaging Details: | Nude packing |
| Delivery Time: | 40 days |
| Payment Terms: | 30%T/T deposit, balance by T/T before shipment |
| Supply Ability: | 40 sets/month |
Application
SR series single shaft shredder is a crushing machine with perfect design. It's widely used and qualified to shred aluminum scraps. The suitable screen can be chosen according to fed materials and the next processing requirement.
Hydraulic system makes pushing device run and motors pass power into rotor by belt and gearbox. Rotor upper and bottom stator blades will work as cutting motion. Materials are fed into the hopper and pushed by pushing chamber between rotor blades, upper and bottom stator blades. After being shred, fed materials will become granules.
Rotor: V type configuration with edge cutters on two sides to prevent material accumulation.
Rotor is made of bead welding and wearing layer processing with the merit of long-life shredding very hard & wear-resistant materials.
Pushing device: Its outer steel plate and pushing chamber are finely processed and kept space. Pushing chamber is made of thickening-processed bottom plates which prevent materials from causing big influence on them.
Screen: Various screens can be chosen for different shredding requests and materials.
To keep operator safe, machine will automatically stop when its screen is opened.
Power device: smart hydraulic control, when fragile materials are shred, oil cylinder will run at the best speed.
Specification
| ItemType | RotationDiameter(MM) | Rotate Speed(rpm) | Screen Diameter(MM) | Number Of Rotor Blade(pcs) | NumberOf Stator Blade(pcs) | MotorPower(kw) |
| SRM600 | 300 | 21 | 20 | 15 | 1 | 11 |
| SRM800 | 300 | 32 | 20 | 20 | 2 | 15 |
Service
1) Free product documents translation into your language, worry-free to operate and maintain.
2) Engineers available to service machinery overseas.
3) Customer database with all customers' records in it.
4) 7*24 technical phone service.
5) One year guarantee and lifelong maintenance.
6) Spare parts: one set of spare parts for free, tool box, operation book.
FAQ
1) Are you a factory or a trade company?
We are manufacturer with own factory for more than 30 years.
2) How can I trust your company?
A. With professional design and sales team, we can serve you the perfect solution with lowest cost.
B. Assessed by third party, national patents for all equipment.
C. Welcome to inspect any time, we are near Shanghai airport.
D. About the machine, we are the first manufacturer of briquette machine, hydraulic balers, alligator shears, shredders are also our main products.
3) Is your price competitive?
Surely we will give you best factory price based on superior product and service.
Contact us! We would like to tell you more about our metal shredder.
