| Place of Origin: | Jiangyin, China |
| Brand Name: | Ecohydraulic |
| Model Number: | Q91Y-630 |
| Certification: | ISO, CE |
| Minimum Order Quantity: | 1 set |
| Price: | FOB Shanghai, USD98000~USD110000 |
| Packaging Details: | Nude packing |
| Delivery Time: | 30 days |
| Payment Terms: | 30%T/T deposit, balance by T/T before shipment |
| Supply Ability: | 15 sets/month |
Application
Gantry shear is heavy duty shear equipment suitable for shearing heavy scrap steel. Our shear is used for light and thin steel, steel bar, steel plate, nickel plate, steel plate, round steel, steel pipe, scrap copper, scrap iron, light metal structural parts, stainless steel, metal block, automobile body, aluminum alloy, copper material, scrap iron, steel wire, metal block, etc. The scrap metal is cut short in cold state and processed into qualified burden. Gantry shearing machine has a wide range of applications. Our gantry shear can be used not only as a processing equipment for metal recovery processing units, but also as a furnace material processing equipment for foundry workshop and metal cutting processing equipment for mechanical construction industry.
Our heavy-duty metal shear adopting the upper-compression and two-side compression scrap steel shaping and segmented feeding mode, combined with the design of the wide material box, so it has good adaptability to scrap steel materials. High density after shearing
The opening area of our shear chamber is large, and it can be used for mechanical feeding. It is suitable for loose and light scrap steel and steel structural parts, especially suitable for steel pipes, steel plates, channel steels, etc. Profile cutting
Using the screen display control panel, automatic integrated control, stable and reliable operation. Optional wireless remote-control device, single operation equipment supporting equipment.
Specification
Heavy-duty hydraulic shears are suitable for compressing and cutting thin & light materials, production and living scrap steel, light metal structural parts, scrap car body, wheel hub, old home alliances, plastic non-ferrous metals (stainless steel, aluminum alloy, copper, etc), or used to compress and bale the above mentioned materials.
The machine is able to:
A) Prepressing and cut scrap
B) Cut bars
C) Packages light scrap
D) Squeeze and cut car bodies
| Model | Q91Y-630 |
| Shearing force (kn) | 6300 |
| Work bin size (mm) | 8000*1800*800 |
| Blade length (mm) | 1800 |
| Max. cutting standard (mm) | Steel plate:80*600Square steel:120*120Round steel:Φ130 |
| Shearing frequency (times/min) | 3~5 |
| Total power (kw) | 45*5 |
| Machine weight (t) | About 60 |
Service
1) Free product documents translation into your language, worry-free to operate and maintain.
2) Engineers available to service machinery overseas.
3) Customer database with all customers' records in it.
4) 7*24 technical phone service.
5) One year guarantee and lifelong maintenance.
6) Spare parts: one set of spare parts for free, tool box, operation book.
FAQ
1) Are you a factory or a trade company?
We are manufacturer with own factory for more than 30 years.
2) How can I trust your company?
A. With professional design and sales team, we can serve you the perfect solution with lowest cost.
B. Assessed by third party, national patents for all equipment.
C. Welcome to inspect any time, we are near Shanghai airport.
D. About the machine, we are the first manufacturer of briquette machine, hydraulic balers, alligator shears, shredders are also our main products.
3) Is your price competitive?
Surely we will give you best factory price based on superior product and service.
